LCD Display Belt Scale Weighing Indicator Industrial Flow Totalizer Controller — B2B belt-scale controller selection with Max connect: 8 load cells; Open Switch Input: 3DI; Open Relay Output: 4DO.
Belt Scales · Buyer selection route
This LCD belt-scale instrument is listed for continuous flow indication and totalisation. The current selection data covers a maximum connection of 8 load cells, 3 digital inputs, 4 relay outputs and IP65 front-panel protection.
Capacity and option guidance
Application route
Operating workflow
Selection checkpoint
| Parameter | Specification |
|---|---|
| Max connect | 8 load cells |
| Open Switch Input | 3DI |
| Open Relay Output | 4DO |
| Protection level of front panel | IP65 |
| Accuracy Grade | 0.5 |
| Accuracy of Flow Control | 0.5%~1.0% |
| COM1 | optional RS232/RS485 |
| COM2 | RS232 |
| Power Supply | AC220V |
Use the listed configuration to evaluate continuous belt-flow indication and totalisation. Its role is defined by the application and control workflow, not by a generic controller label alone.
For comparison with another model, document the required live flow, accumulated total and host-system reporting fields. The parameter table retains every reviewed buyer-facing field available for this record.
Before ordering, confirm conveyor survey, speed sensing, load-cell arrangement, totalisation workflow and calibration method. Any performance value remains conditional on the exact model, installation and agreed verification procedure.
Compare LCD flow totalizer as belt flow totalizer and indicator for a surveyed conveyor weighing or control task.
What distinguishes this product: LCD flow totalizer lists Max connect: 8 load cells; Open Switch Input: 3DI.
The controller does not establish the complete weigh frame, idlers, speed sensing, conveyor condition or installed result.
Compare 1 available configuration by technical fields and product images, then confirm the option that fits your application.
Configuration: LCD Display Belt Scale Weighing Indicator Industrial Flow Totalizer Controller
| Parameter | Current value |
|---|---|
| Max connect | 8 load cells |
| Open Switch Input | 3DI |
| Open Relay Output | 4DO |
| Protection level of front panel | IP65 |
| Accuracy Grade | 0.5 |
| Accuracy of Flow Control | 0.5%~1.0% |
| COM1 | optional RS232/RS485 |
| COM2 | RS232 |
| Power Supply | AC220V |
5 product images shown in the model gallery.
Use this checklist to prepare the equipment and application information needed to match LCD Display Belt Scale Weighing Indicator Industrial Flow Totalizer Controller to your project.
Product-specific focus: LCD flow totalizer, including Max connect: 8 load cells, and the installed operating workflow.
| Selection checkpoint | Information to confirm before order |
|---|---|
| Primary application data | Purpose: monitoring, inventory, control or trade |
| Mechanical compatibility | Material, density, particle size and environment |
| Load and operating envelope | Minimum, normal and maximum flow |
| Measurement workflow | Belt width, speed, incline and idler geometry |
| Site and integration conditions | Installation straight length and interference points |
| Verification and responsibility | Calibration method, outputs, PLC/DCS and responsibility |
